Kia Rio: 4Door Interior
|
|
|
|
| Front pillar trim mounting hole (Ø8.5) |
Curtain airbag mounting hole (Ø6.6) |
Cowl crossbar mounting hole (Ø6.6) |
|
|
|
|
| Front pillar inner panel tooling hole (7X12) |
Front door checker mounting hole (Ø11) |
Seat belt height adjuster mounting hole (Ø16) |
|
|
|
|
| Seat belt height adjuster mounting hole (Ø16) |
Seat belt retractor mounting hole (Ø12) |
Rear door checker mounting hole (Ø11) |
|
|
|
|
| Curtain airbag mounting hole (Ø6.6) |
Curtain airbag mounting hole (Ø6.6) |
Quarter inner lower panel tooling hole (Ø8.5) |
|
|
|
|
| Quarter inner lower panel tooling hole (Ø10) |
Rear door striker mounting hole (Ø13) |
4Door Side Body
