Kia Cee'd: Brake System / Front Disc Brake Components and components location
Kia Cee'd JD Service Manual / Brake System / Brake System / Front Disc Brake Components and components location
| Components |
| 1. Guide rod bolt 2. Bleed screw 3. Caliper carrier 4. Caliper body |
5. Inner pad shim 6. Brake pad 7. Pad retainer 8. Return spring |
Brake Pedal Repair procedures
Removal [LHD]
1.
Turn ignition switch OFF and disconnect the negative (-) battery cable.
2.
Remove the crash pad lower panel.
...
Front Disc Brake Repair procedures
Removal
1.
Remove the front wheel & tire.
Tightening torque:
88.3 ~107.9 N.m (9.0 ~11.0 kgf.m, 65.1 ~79.6 lb-ft)
...
